Features
* In accordance with international standard ASTMD523, ASTMD1455, ASTMC346, ASTMC584, ASTMD2457, DIN ENISO2813, DIN67530, ENISO7668, JISZ8741, MFT30064, TAPPIT480, GB9754, GB/T13891, GB7706 and GB8807. Its technical parameters conform with JJG696-2002.
* Accurate measurement, good repetitveness.
* Small in size, easy to carry.
* Auto calibration.
* Intelligent design, rapid measurement.
* Able to store 254 groups of measurements.
* Built-in lithium ion rechargeable battery.
* Backlight display, suitable for low light environment.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
Material And Angle Selection Recommended
-
20°: High gloss paint, printing ink, plastics, paper and other materials.
-
60°: Middle gloss paint, printing ink, plastics, ceramics, marble and other materials.
-
85°: Low gloss paint, camouflage coatings materials.
Specifications
|
Display
|
4 Digits Backlit LCD
|
|
Measuring Angle
|
60º
|
|
Range
|
0.1GU~200 GU
|
|
Gloss Units
|
GU
|
|
Accuracy
|
±1.0GU
|
|
Resoltuion
|
0.1
|
|
Repeatability
|
±0.5GU
|
|
Measuring Area
|
7mmx14mm（Ellipse）
|
|
Data Memorized
|
254 Groups
|
|
Operating Conditions
|
Temp:0ºC~40ºC Humidity:<85%RH
|
|
Power Supply
|
4x1.5V AAA Size(UM-4)Battery
|
|
Dimensions
|
Main Unit:156mmx67mmx28mm
|
|
Probe:58mmx28mmx108mm
|
|
Weight
|
190g(Not Including Batteries)
|
|
Stabdard Accessories
|
Main Unit
|
|
Holder with Calibration Standard
|
|
External Probe
|
|
Optical Cleaning Cloth
|
|
Carrying Case(B04)
|
|
Operation Manual
|
